GLASS PASSIVATED BRIDGE RECTIFIE
All alternatives
View full reportTechnical parameters
Key specs
Reverse voltage1 kV
Average rectified current1 A
Forward voltage1.1 VMax · 1 A
TypeStandard
| Power | |
|---|---|
| Current - Average Rectified (Io) | 1 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 1000 V |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 1 A |
| Voltage - Peak Reverse (Max) | 1 kV |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~150°C(TJ) |
| Package | Tube |
| Package / Case | 4-SMD, Gull Wing |
| Supplier Device Package | DBS |
| Other | |
| Diode Type | Single Phase |
| Mfr | HY Electronic (Cayman) Limited |
| Product Status | Active |
| Series | DB |
| Technology | Standard |
Documents
No documents are linked to this part yet.
