View full reportTechnical parameters
| Power | |
|---|---|
| Voltage | 300 V |
| Environment and package | |
| Operating Temperature | -55°C ~ 200°C |
| Package | Spool |
| Other | |
| Base Product Number | 100057 |
| Cable Type | Flat Cable |
| Conductor Material | Copper, Silver Coated |
| Conductor Strand | 7 Strands / 36 AWG |
| Features | - |
| First Conductor Mark | Blue |
| Insulation Resistance | - |
| Jacket Color | Blue |
| Jacket (Insulation) Material | Fluorinated Ethylene-Propylene (FEP) |
| Length | 50.0' (15.24m) |
| Mfr | Molex - Temp Flex |
| Number of Conductors | 34 |
| Pitch | 0.050" (1.27mm) |
| Product Status | Discontinued at Digi-Key |
| Ratings | UL Style 20424 |
| Ribbon Thickness | - |
| Ribbon Width | 1.700" (43.18mm) |
| Series | Temp-Flex 100057 |
| Shielding | Unshielded |
| Wire Gauge | 28 AWG |
