View full reportTechnical parameters
Key specs
Input voltage100 ~ 240 V
Output voltage28 V
Output current8 AMax
Power225 WMax
Outputs1
| Power | |
|---|---|
| Current - Output 1 | 8 A |
| Power (Watts) | 225W |
| Voltage - Input | 100 ~ 240 VAC |
| Voltage - Output 1 | 28V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | 0°C ~ 70°C (With Derating) |
| Size / Dimension | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) |
| Other | |
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE, cURus, TUV, UKCA |
| Efficiency | 85% |
| Features | Adjustable Output, Remote Sense, Universal Input |
| Mfr | Integrated Power Designs |
| Minimum Load Required | - |
| Number of Outputs | 1 |
| Packaging | Box |
| Part Status | Active |
| Series | NXT-225 (225W) |
| Standard Number | 60601-1; 62368-1 |
| Type | Open Frame |
