Adels-ContactGermany
CONN TERM STRIP 3CIRC 0.531"
All alternatives
View full reportTechnical parameters
Key specs
Rows2
Pitch13.5 mm
Current rating57 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 57A |
| Voltage Rating | 500V |
| Environment and package | |
| Mounting Type | Chassis, Panel |
| Operating Temperature | 85°C |
| Package | Bulk |
| Other | |
| Barrier Type | Enclosed |
| Bottom Termination | Closed |
| Color | Natural |
| Features | - |
| Material Flammability Rating | UL94 V-2 |
| Material - Insulation | Polyamide (PA6), Nylon 6 |
| Mfr | Adels-Contact |
| Number of Circuits | 3 |
| Number of Rows | 2 |
| Number of Wire Entries | 6 |
| Pitch | 0.531" (13.50mm) |
| Product Status | Active |
| Series | - |
| Terminal Block Type | Eurostyle Terminal Strip |
| Terminal Screw Finish | - |
| Terminal Screw Material | - |
| Top Termination | Screws |
| Wire Gauge | 8-20 AWG |
