131-8701-506
ActiveExplore the 131-8701-506 RF & Microwave Connectors from Cinch. View specs, download models, request a quote, and check stock. Highly reliable connectivity solutions that support engineers’ designs. Order now for seamless integration and enduring reliability.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Working Voltage (Vrms) | 335 |
| AC and DC characteristics | |
| Impedance (Ohms) | 75 |
| Max Frequency (GHz) | 2 |
| Environment and package | |
| Mounting Style | Bulkhead Mount |
| Operating Temp. Range (°C) | -65 to +165 |
| Other | |
| Body Finish | Nickel |
| Body Material | Brass |
| Body Style | Right Angle |
| Brand | Johnson |
| Contact Material | Beryllium Copper |
| Contact Plating | Gold |
| Durability (Cycles Min) | 500 |
| Gender | Jack |
| Insulation Resistance (mOhms Min) | 1000 |
| Insulator | PTFE |
| Number of Ports | 1 |
| Series | SMB |
| Termination Style | Printed Circuit Board |
| Termination Type | Solder |
| Type | Standard |
