132136
AmphenolUnited States

132136

ActiveCoaxial Connector (RF) Assemblies

CONN SMA JACK R/A 50 OHM PCB

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleSMA
GenderFemale
Impedance50 Ω
Max frequency6 GHzMax
AC and DC characteristics
Frequency - Max6 GHz
Impedance50Ohm
Environment and package
Mounting Feature-
Mounting TypeThrough Hole, Right Angle
Operating Temperature-65°C~165°C
PackageBag
Other
Base Product Number1321
Body FinishGold
Body MaterialBrass
Cable Group-
Center Contact MaterialBeryllium Copper
Center Contact PlatingGold
Connector StyleSMA
Connector TypeJack, Female Socket
Contact TerminationSolder
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeThreaded
Features-
Housing ColorGold
Includes-
Ingress Protection-
Insertion Loss-
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationSolder
