Phoenix ContactGermany
CONN PLUG MALE 5POS SOLDER CUP
All alternatives
View full reportTechnical parameters
Key specs
Positions5
GenderMale
Current rating4 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 4A |
| Voltage Rating | 60V |
| Environment and package | |
| Mounting Feature | Bulkhead - Rear Side Nut |
| Mounting Type | Panel Mount |
| Operating Temperature | -25°C~85°C |
| Package | Bulk |
| Shell Size - Insert | M12-5 |
| Shell Size, MIL | - |
| Other | |
| Applications | - |
| Backshell Material, Plating | - |
| Cable Opening | - |
| Color | Black |
| Connector Type | Plug, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | - |
| Contact Material | Copper Zinc |
| Fastening Type | Threaded |
| Features | - |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Insert Material | Polyamide (PA66), Nylon 6/6 |
| Material Flammability Rating | UL94 HB |
| Mfr | Phoenix Contact |
| Number of Positions | 5 |
| Orientation | A |
| Primary Material | Plastic |
| Product Status | Active |
| Series | SACC |
| Shell Finish | - |
| Shell Material | Polyamide (PA66), Nylon 6/6 |
| Shielding | - |
| Termination | Solder Cup |
