View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Voltage Rating | 150V |
| Environment and package | |
| Mounting Type | Through Hole, Right Angle |
| Operating Temperature | -40°C~105°C |
| Package | Tray |
| Other | |
| Base Product Number | 171990 |
| Color | Black |
| Connector Style | Impel™ |
| Connector Type | Receptacle, Female Sockets and Blade Sockets |
| Connector Usage | Daughtercard |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Layout, Typical | 24 Differential Pairs |
| Features | Shielded |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Molex |
| Number of Columns | 8 |
| Number of Positions | - |
| Number of Positions Loaded | All |
| Number of Rows | 9 |
| Pitch | 0.075" (1.90mm) |
| Product Status | Active |
| Series | Impel 171990 |
| Termination | Press-Fit |
Documents
No documents are linked to this part yet.
