Comair RotronUnited States
FAN AXIAL 120X32MM 24VDC MC24B7
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.230A |
| Power (Watts) | 5.5 W |
| Voltage Range | 12 ~ 28VDC |
| Voltage - Rated | 24VDC |
| AC and DC characteristics | |
| Noise | 47.8dB(A) |
| Environment and package | |
| Lifetime @ Temp. | 75000 Hrs @ 40°C |
| Operating Temperature | 14~158°F(-10~70°C) |
| Package | Box |
| Size / Dimension | Square - 120mm L x 120mm H |
| Other | |
| Air Flow | 102.0 CFM (2.86m³/min) |
| Approval Agency | CE, UL |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Locked Rotor Protection, Speed Sensor (Tach) |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Comair Rotron |
| Product Status | Active |
| RPM | 3700 RPM |
| Series | Muffin |
| Static Pressure | 0.350 in H2O (87.2 Pa) |
| Termination | 3 Wire Leads |
| Weight | 0.529 lb (239.95 g) |
| Width | 32.00mm |
