View full reportTechnical parameters
Key specs
Positions4
Pitch5.08 mm
| Power | |
|---|---|
| Current - IEC | 12A |
| Current - UL | 10 A |
| Voltage - IEC | 250 V |
| Voltage - UL | 300 V |
| Environment and package | |
| Insulation Height | 0.591" (15.00mm) |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | - |
| Screw Size | - |
| Other | |
| Color | Green |
| Contact Material | - |
| Contact Mating Finish | Tin |
| Contact Tail Length | - |
| Features | Positions Stamped, Retention Latches (Non-Wire Side) |
| Header Orientation | - |
| Housing Material | - |
| Ingress Protection | - |
| Manufacturer | Phoenix Contact |
| Material Flammability Rating | - |
| Number of Levels | 1 |
| Number of Positions | 4 |
| Packaging | Bulk |
| Part Status | Active |
| Pitch | 0.200" (5.08mm) |
| Plug Wire Entry | 180° |
| Positions Per Level | 4 |
| Series | COMBICON FKC |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Torque - Screw | - |
| Type | Plug, Female Sockets |
| Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm² | 0.2-2.5mm² |
| Wire Strip Length | 10mm |
