242193
AmphenolUnited States

242193

ActiveCoaxial Connector (RF) Adapters

CONN ADAPT MMCX PLUG TO SMA JACK

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Frequency - Max6 GHz
Impedance50Ohm
Environment and package
Mounting FeatureBulkhead
Mounting TypePanel Mount
Operating Temperature-65°C~165°C
PackageBag
Other
Adapter SeriesSMA to MMCX
Adapter TypePlug to Jack
Base Product Number2421
Body FinishGold
Body MaterialBrass
Center Contact MaterialBeryllium Copper
Center Contact PlatingGold
Center GenderFemale to Male
Conversion TypeBetween Series
Convert From (Adapter End)MMCX Plug, Male Pin
Convert To (Adapter End)SMA Jack, Female Socket
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeSnap-On, Threaded
Features-
Includes3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Ingress Protection-
Insertion Loss-
Mating Cycles-
MfrAmphenol RF
Product StatusActive
Series-
StyleStraight
