242198
AmphenolUnited States

242198

ActiveCoaxial Connector (RF) Adapters

CONN ADAPT SMB JACK TO N JACK

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Frequency - Max4 GHz
Impedance50Ohm
Environment and package
Mounting FeatureFlange
Mounting TypePanel Mount
Operating Temperature-65°C~165°C
PackageBag
Other
Adapter SeriesN to SMB
Adapter TypeJack to Jack
Base Product Number2421
Body FinishNickel
Body MaterialBrass
Center Contact MaterialPhosphor Bronze
Center Contact PlatingGold
Center GenderFemale to Male
Conversion TypeBetween Series
Convert From (Adapter End)SMB Jack, Male Pin
Convert To (Adapter End)N Jack, Female Socket
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeSnap-On, Threaded
Features-
Includes-
Ingress Protection-
Insertion Loss-
Mating Cycles-
MfrAmphenol RF
Product StatusActive
Series-
StyleStraight

Documents

DatasheetDatasheet · 210.7 KB · 2026-09-22OtherOther · 3.9 MB · 2026-09-22OtherOther · 491.9 KB · 2026-09-22OtherOther · 395.3 KB · 2026-09-22OtherOther · 303.8 KB · 2026-09-22OtherOther · 282.2 KB · 2026-09-22OtherOther · 258.8 KB · 2026-09-22OtherOther · 251.8 KB · 2026-09-22OtherOther · 250.7 KB · 2026-09-22OtherOther · 236.2 KB · 2026-09-22OtherOther · 204.3 KB · 2026-09-22OtherOther · 200.0 KB · 2026-09-22OtherOther · 199.3 KB · 2026-09-22OtherOther · 182.2 KB · 2026-09-22OtherOther · 181.9 KB · 2026-09-22
