AmphenolUnited States
CONN ADAPT BNC JACK TO F PLUG
All alternatives
View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Impedance | - |
| Environment and package | |
| Mounting Feature | - |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | - |
| Package | Bag |
| Other | |
| Adapter Series | BNC to F |
| Adapter Type | Plug to Jack |
| Base Product Number | 2421 |
| Body Finish | Nickel |
| Body Material | Brass |
| Center Contact Material | Phosphor Bronze |
| Center Contact Plating | Gold |
| Center Gender | Female to Male |
| Conversion Type | Between Series |
| Convert From (Adapter End) | BNC Jack, Female Socket |
| Convert To (Adapter End) | F Plug, Male Pin |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Fastening Type | Bayonet Lock, Threaded |
| Features | - |
| Includes | - |
| Ingress Protection | - |
| Insertion Loss | - |
| Mating Cycles | - |
| Mfr | Amphenol RF |
| Product Status | Active |
| Series | - |
| Style | Straight |
Documents
DatasheetDatasheet · 46.6 KB · 2026-09-21OtherOther · 1023.9 KB · 2026-09-22OtherOther · 711.5 KB · 2026-09-22OtherOther · 338.2 KB · 2026-09-22OtherOther · 249.5 KB · 2026-09-22OtherOther · 236.0 KB · 2026-09-22OtherOther · 200.0 KB · 2026-09-22OtherOther · 156.5 KB · 2026-09-22OtherOther · 82.3 KB · 2026-09-22
Open document center
