WeidmüllerGermany
SURGE PROTECTION - OVP
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Discharge (Max) (8/20µS) | 50 kA |
| Current - Discharge (Nom) (8/20µS) | 20 kA |
| Current - Short Circuit Rating (SCRR) | 200 kA |
| Voltage - Continuous Operating (Max) (MCOV) | 150V |
| Voltage - Protection Level (VP) (2416) | 1.25 kV |
| Voltage - Protection Rating (VPR) | 1 kV |
| Environment and package | |
| Mounting Type | DIN Rail |
| Operating Temperature | -40°C~85°C |
| Package | Box |
| Other | |
| Approval Agency | cULus, VDE |
| Features | Remote Signaling Contacts |
| Form | Base + Module |
| Mfr | Weidmüller |
| Number of Poles | 2 |
| Product Status | Active |
| Series | VPU |
| Type | Surge Protection Module |
