View full reportTechnical parameters
| Power | |
|---|---|
| Current - Drain (Idss) @ Vds (Vgs=0) | 80 µA @ 10 V |
| Power - Max | 300 mW |
| Voltage - Breakdown (V(BR)GSS) | 40 V |
| Voltage - Cutoff (VGS off) @ Id | 1 V @ 1 nA |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Package / Case | TO-206AF, TO-72-4 Metal Can |
| Supplier Device Package | TO-206AF (TO-72) |
| Other | |
| Base Product Number | 2N4118 |
| FET Type | N-Channel |
| Input Capacitance (Ciss) (Max) @ Vds | 3pF @ 10V |
| Manufacturer | Vishay Siliconix |
| Packaging | Bulk |
| Part Status | Obsolete |
| Series | - |
