Rohm SemiconductorJapan
TRANS NPN 120V 1.5A SOT89
All alternatives
View full reportTechnical parameters
Key specs
TypeNPN
Collector-emitter voltage120 V
Collector current1.5 AMax
DC current gain120200mA
Power500 mWMax
| Power | |
|---|---|
| Current - Collector Cutoff (Max) | 1µA (ICBO) |
| Current - Collector (Ic) (Max) | 1.5 A |
| Power - Max | 500 mW |
| Voltage - Collector Emitter Breakdown (Max) | 120 V |
| AC and DC characteristics | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 120 @ 200mA, 5V |
| Frequency - Transition | 200MHz |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C(TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | TO-243AA |
| Supplier Device Package | SOT-89 |
| Other | |
| Mfr | Rohm Semiconductor |
| Product Status | Active |
| Series | - |
| Transistor Type | NPN |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 80mA, 800mA |
