View full reportTechnical parameters
| Power | |
|---|---|
| Current - IEC | 17.5 A |
| Current - UL | 15 A |
| Voltage - IEC | 450 V |
| Voltage - UL | 300 V |
| Environment and package | |
| Height (Max) | 0.736" (18.70mm) |
| Mounting Type | Direct Mount |
| Operating Temperature | -60°C~130°C |
| Package | Bulk |
| Other | |
| Features | Block of 3 |
| Housing Color | Blue |
| Length | 0.850" (21.60mm) |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polyamide (PA), Nylon |
| Mfr | Phoenix Contact |
| Number of Levels | 1 |
| Number of Positions | 6 |
| Product Status | Active |
| Series | CLIPLINE PTFIX |
| Stripping Length | 10mm |
| Terminal - Width | 12.5mm |
| Termination Style | Push In, Spring |
| Type | Middle |
| Wire Gauge or Range - AWG | 14-26 AWG |
| Wire Gauge or Range - mm² | 0.14-1.5mm² |
