View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | 32D |
| Other | |
| Cp@1KHZ（pF） | 3100 |
| Ip (A) | 200 |
| Ipp(8/20μs)I Max. | 25 |
| Ipp(8/20μs)In.10 times | 15 |
| V1mA(V)(Max.) | 473 |
| V1mA(V)(Min.) | 387 |
| VAC(V) | 275 |
| Vc (V) | 710 |
| VDC(V) | 350 |
| Environment and package | |
|---|---|
| Package | 32D |
| Other | |
| Cp@1KHZ（pF） | 3100 |
| Ip (A) | 200 |
| Ipp(8/20μs)I Max. | 25 |
| Ipp(8/20μs)In.10 times | 15 |
| V1mA(V)(Max.) | 473 |
| V1mA(V)(Min.) | 387 |
| VAC(V) | 275 |
| Vc (V) | 710 |
| VDC(V) | 350 |
