SCHURTER Inc.Switzerland
FUSE BOARD MNT 1.25A 125VAC/VDC
All alternatives
View full reportTechnical parameters
Key specs
Rated current1.25 A
Rated voltage125 V
Response timeFast
Breaking capacity100 A
| Power | |
|---|---|
| Breaking Capacity @ Rated Voltage | 100A |
| Current Rating (Amps) | 1.25 A |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 125 V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~125°C |
| Package | Tape & Reel (TR) |
| Package / Case | 2-SMD, J-Lead |
| Size / Dimension | 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm) |
| Other | |
| Approval Agency | cURus |
| Base Product Number | 3404.0010 |
| Color | - |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 0.14 |
| Mfr | SCHURTER Inc. |
| Product Status | Active |
| Response Time | Fast Blow |
| Series | OMF 125 |
