IMS Connector SystemsGermany
All alternatives
View full reportTechnical parameters
Key specs
Impedance50 Ω
| AC and DC characteristics | |
|---|---|
| Impedance | 50 Ohm |
| Environment and package | |
| Mounting style PCB | Edge mount type |
| Other | |
| Application | Small Cell Connectors, Antenna Connectors |
| Fitting position | Rear mounting |
| Locking mechanism | Threaded Types |
| Male / Female | Female |
| Markets | Communication, Industrial |
| Packaging | Bulk packaging |
| Panel thickness max | 3.2 mm |
| Panel thickness min | 1 mm |
| Plating | 1 = Au; 5 = White bronze |
| Product style | Bulkhead p.c.b. mount jack |
| Product termination | PCB connector |
| Series | SMA |
| Straight / Angle | Straight |
