All alternatives
View full reportTechnical parameters
Key specs
Positions5
GenderFemale
Current rating4 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 4A |
| Voltage Rating | 60V |
| Environment and package | |
| Mounting Feature | - |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | -30°C ~ 85°C |
| Shell Size - Insert | M12-5 |
| Shell Size, MIL | - |
| Other | |
| Applications | - |
| Backshell Material, Plating | Polyamide (PA6), Nylon 6, Glass Filled |
| Cable Opening | 0.157" ~ 0.236" (4.00mm ~ 6.00mm) |
| Color | Black, Silver |
| Connector Type | Plug, Female Sockets |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | - |
| Contact Material | Copper Zinc |
| Fastening Type | Threaded |
| Features | Backshell, Coupling Nut |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Insert Material | Polyamide (PA6), Nylon 6 |
| Material Flammability Rating | UL94 |
| Mfr | Amphenol CONEC |
| Number of Positions | 5 |
| Orientation | A |
| Packaging | Bulk |
| Part Status | Obsolete |
| Primary Material | Plastic |
| Series | 43 |
| Shell Finish | - |
| Shell Material | Polyamide (PA6), Nylon 6, Glass Filled |
| Shielding | Unshielded |
| Termination | Screw |
