518-95AB-MS4
Wakefield-VetteUnited States

518-95AB-MS4

ObsoleteHeat Sinks

HEATSINK DC/DC HALF BRICK VERT

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Environment and package
Fin Height0.950" (24.13mm)
PackageBulk
Package CooledHalf Brick DC/DC Converter
Power Dissipation @ Temperature Rise11.0W@60°C
Thermal Resistance @ Forced Air Flow2.00°C/W @ 300 LFM
Thermal Resistance @ Natural-
Other
Attachment MethodBolt On, Thermal Material
Diameter-
Length2.402" (61.00mm)
MaterialAluminum
Material FinishBlack Anodized
MfrWakefield-Vette
Product StatusObsolete
Series518
ShapeRectangular, Fins
Shelf Life-
TypeBoard Level
Width2.280" (57.91mm)

Documents

No documents are linked to this part yet.
