View full reportTechnical parameters
| Power | |
|---|---|
| Power - Max | 3 W |
| AC and DC characteristics | |
| Frequency (Center/Band) | 5.8GHz |
| Frequency Group | SHF (f > 4GHz) |
| Frequency Range | 5.725GHz ~ 5.825GHz |
| Gain | 3.9dBi |
| Environment and package | |
| Height (Max) | 0.047" (1.20mm) |
| Mounting Type | Surface Mount |
| Other | |
| Antenna Type | Chip |
| Applications | - |
| Features | - |
| Ingress Protection | - |
| Manufacturer | Johanson Technology Inc. |
| Number of Bands | 1 |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Return Loss | -9.5dB |
| RF Family/Standard | - |
| Series | - |
| Termination | Solder |
| VSWR | - |
