6004
ActiveThe 6004 Series of stainless steel flange thermistor probes is an ideal choice for air and gas (open-tip model recommended) temperature measurement. These sensors are available in a variety of sizes and flange shapes, with open or closed tips, and with or without brazed flanges. The flanged mount design allows for easy installation in tight areas. This series can be used in mechanical rooms, pipes, ducts, and immersion installations to provide accurate temperature measurements. Mounting flange is pre-drilled with a #6 hole to provide easy installation. CTS components are stocked and sold through a global network of distributors & sales representatives. Select your preferred partner in the link below.
All alternatives
View full reportTechnical parameters
| Environment and package | |
|---|---|
| Sensor Mount | Flange |
| Temperature Range | -40°–125° |
| Other | |
| Beta Value | 3977, 3435, 3690, 4260, Custom |
| Material | Stainless steel |
| Resistance | 10000 / 100000 / 2252 / 3000 / 30000 / 5000 / 50000 / Custom / Pt100 / Pt1000 |
| Sensor Type | Platinum RTD Thermistor |
| Tolerance | 0.1C (0C to 70C) / 0.2C (0C to 70C) / 1% / 2% / 5% / Custom |
