Song Chuan(松川)China
Optional for open frame, dust cover, sealed type and with/without quick terminal on top.; High rating 20A 240VAC.; Ideal for home appliances application, specially for heating control use.
All alternatives
View full reportTechnical parameters
Key specs
Coil voltage5 ~ 110 V
| Power | |
|---|---|
| Coil voltage | DC | 5 ~ 110V |
| Max. Allowable Contact current(A) | 20 A |
| Power consumption | DC | 0.7W |
| Other | |
| 1. | 805 | — | Basic series designation |
| 2. | Blank | — | PCB terminal |
| 3. | 1A | — | Single pole normally open |
| 4. | C | — | Contact material AgNi |
| 5. | Blank | — | Standard type |
| 6. | Blank | — | Open type |
| 7. | Blank | — | Standard type |
| 8. | □ | — | Coil voltage (please refer to the coil rating data for the availability) |
| AC | —— |
| Contact and coil | 2500VAC |
| Contact circuits | —— |
| Contact configuration | 1A, 1C |
| Contact rating | Resistive load | 20A 240VAC |
| Dielectric strength | Open contact | 1000VAC |
| Electrical(Min.) | 1×105 |
| Life expectancy | Mechanical(Min.) | 1×107 |
| Outline (L×W×H) mm | 32.2 × 27.5 × 20.4 |
