All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Power (Watts) | 11.00W |
| Voltage Range | - |
| Voltage - Rated | 115VAC |
| AC and DC characteristics | |
| Noise | 34.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | - |
| Package | Box |
| Size / Dimension | Square - 80mm L x 80mm H |
| Other | |
| Air Flow | 36.0 CFM (1.01m³/min) |
| Approval Agency | CSA, UL, VDE |
| Bearing Type | Sintec |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Material - Blade | Metal |
| Material - Frame | Metal |
| Mfr | ebm-papst Inc. |
| Product Status | Obsolete |
| RPM | - |
| Series | 8000V |
| Static Pressure | - |
| Termination | 2 Terminals |
| Weight | 1.1 lbs (499.0 g) |
| Width | 38.00mm |
Documents
No documents are linked to this part yet.
