PCTEL, Inc.United States
RF ANT 1.621GHZ MOD RP-TNC MAG
All alternatives
View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Frequency (Center/Band) | 1.621GHz |
| Frequency Group | UHF (1GHz ~ 2GHz) |
| Frequency Range | 1.616GHz ~ 1.6265GHz |
| Gain | 4dBic |
| Environment and package | |
| Height (Max) | 0.535" (13.60mm) |
| Mounting Type | Magnetic |
| Package | Bulk |
| Other | |
| Antenna Type | Module |
| Applications | GNSS |
| Features | Cable - 3.6576m, LNA, Filter |
| Ingress Protection | IP67 |
| Mfr | PCTEL, Inc. |
| Number of Bands | 1 |
| Product Status | Obsolete |
| Return Loss | - |
| RF Family/Standard | Navigation |
| Series | Iridium® |
| Termination | RP-TNC |
| VSWR | 2 |
Documents
No documents are linked to this part yet.
