Key specs
Positions6
GenderFemale
Current rating2 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 2A |
| Voltage Rating | 30VDC |
| Environment and package | |
| Mounting Feature | - |
| Mounting Type | Through Hole, Right Angle |
| Operating Temperature | -55°C ~ 85°C |
| Shell Size - Insert | Mini DIN |
| Shell Size, MIL | - |
| Other | |
| Applications | - |
| Backshell Material, Plating | - |
| Base Product Number | A-DIO-FS |
| Cable Opening | - |
| Color | Black |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | Flash |
| Contact Material | Brass |
| Fastening Type | Push-Pull |
| Features | Board Guide, Board Lock |
| Ingress Protection | - |
| Insert Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Assmann WSW Components |
| Number of Positions | 6 |
| Orientation | Keyed |
| Packaging | Bulk |
| Part Status | Active |
| Primary Material | Metal |
| Series | - |
| Shell Finish | Nickel |
| Shell Material | Brass |
| Shielding | Unshielded |
| Termination | Solder |
