KYOCERA AVXJapan
AUTOMOTIVE WI-FI 6 & WI-FI 6E ST
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Power - Max | 0.5 W |
| AC and DC characteristics | |
| Frequency (Center/Band) | 2.4425GHz, 3.55GHz, 5.4875GHz, 6.525GHz |
| Frequency Group | Wide Band |
| Frequency Range | 2.4GHz ~ 2.485GHz, 3.3GHz ~ 3.8GHz, 5.15GHz ~ 5.825GHz, 5.925GHz ~ 7.125GHz |
| Gain | 1.7dBi, 4.21dBi, 4.1dBi, 3.8dBi |
| Environment and package | |
| Height (Max) | 0.169" (4.30mm) |
| Mounting Type | Surface Mount |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Other | |
| Antenna Type | Stamped Metal |
| Applications | Bluetooth, Wi-Fi, Wi-Fi 6, Wi-Fi 6E, WLAN, ZigBee |
| Features | - |
| Ingress Protection | - |
| Mfr | KYOCERA AVX |
| Number of Bands | 4 |
| Product Status | Active |
| Return Loss | - |
| RF Family/Standard | 802.15.4, Bluetooth, WiFi |
| Series | A |
| Termination | Solder |
| VSWR | 2, 2.2 |
