View full reportTechnical parameters
| Power | |
|---|---|
| IC-最大集电极电流 | 0.1A |
| VCEO-集射级击穿电压 | 45V |
| AC and DC characteristics | |
| fT-变换频率 | NMHZ |
| hFE-最小直流增益 | 420 |
| Environment and package | |
| 封装类型1 | SOT523 |
| 最大工作温度 | 150℃ |
| Other | |
| Pd-功率耗散 | 0.265W |
| VCE(sat)-集射级饱和压降 | 0.65V |
| 引脚数量1 | 3 |
Documents
DatasheetDatasheet · 622.2 KB · 2026-09-22EnvironmentalEnvironmental · 1.5 MB · 2026-09-22Package DrawingPackage Drawing · 956.9 KB · 2026-09-22EnvironmentalEnvironmental · 874.0 KB · 2026-09-22Package DrawingPackage Drawing · 633.3 KB · 2026-09-22Package DrawingPackage Drawing · 403.2 KB · 2026-09-22
