View full reportTechnical parameters
| Power | |
|---|---|
| IC-最大集电极电流 | 1A |
| VCEO-CE结击穿电压 | 80V |
| VCEO-集射级击穿电压 | 80V |
| AC and DC characteristics | |
| fT-变换频率 | NMHZ |
| hFE-最小直流增益 | 63 |
| Hfe-最小直流增益 | 63 |
| Other | |
| Pd-功率耗散 | 1W |
| Pd-最大功率耗散 | 1W |
