Texas InstrumentsUnited States
IC RF TXRX+MCU ISM<1GHZ 48VFQFN
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Receiving | 15mA ~ 18.5mA |
| Current - Transmitting | 15mA ~ 36mA |
| Power - Output | 13dBm |
| Voltage - Supply | 2V ~ 3.6V |
| AC and DC characteristics | |
| Frequency | 300MHz ~ 348MHz, 389MHz ~ 464MHz, 779MHz ~ 928MHz |
| Environment and package | |
| Memory Size | 32kB Flash, 4kB SRAM |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 48-VFQFN Exposed Pad |
| Supplier Device Package | 48-VQFN (7x7) |
| Other | |
| Base Product Number | CC430F5137 |
| Data Rate (Max) | 500kBaud |
| GPIO | 30 |
| Mfr | Texas Instruments |
| Modulation | 2FSK, 2GFSK, ASK, MSK, OOK |
| Product Status | Active |
| Protocol | - |
| RF Family/Standard | General ISM < 1GHz |
| Sensitivity | -117dBm |
| Serial Interfaces | I²C, IrDA, JTAG, SPI, UART |
| Series | - |
| Type | TxRx + MCU |
Documents
No documents are linked to this part yet.
