AC/DC CONVERTER 24V 120W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage100 ~ 240 V
Output voltage24 V
Output current5 AMax
Power120 WMax
Outputs1
| Power | |
|---|---|
| Current - Output 1 | 5 A |
| Power (Watts) | 120W (175W Forced Air) |
| Voltage - Input | 100 ~ 240 VAC |
| Voltage - Isolation | 4 kV |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -10°C~70°C(WithDerating) |
| Package | Bulk |
| Size / Dimension | 4.00" L x 2.00" W x 1.30" H (101.6mm x 50.8mm x 33.0mm) |
| Other | |
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Base Product Number | CINT1175 |
| Efficiency | 90% |
| Features | Adjustable Output, DC Input Capable, Standby Output, Universal Input |
| Mfr | SL Power Electronics Manufacture of Condor/Ault Brands |
| Minimum Load Required | Yes |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | CINT1175 (175W) |
| Type | Open Frame |
