View full reportTechnical parameters
| Power | |
|---|---|
| Current - Supply | 80 µA |
| Voltage Range | 1.6 V ~ 3.6 V |
| Voltage - Rated | 2 V |
| AC and DC characteristics | |
| Frequency Range | 100 Hz ~ 10 kHz |
| Environment and package | |
| Height (Max) | 0.051" (1.30mm) |
| Size / Dimension | 0.130" Dia (3.30mm) |
| Other | |
| Base Product Number | CMM-3312 |
| Direction | Omnidirectional |
| Manufacturer | Same Sky |
| Output Type | Analog |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Obsolete |
| Port Location | Top |
| Ratings | - |
| Sensitivity | -44dB ±3dB @ 94dB SPL |
| Series | CMM |
| Shape | Circular |
| S/N Ratio | 58dB |
| Termination | Solder Pads |
| Type | MEMS (Silicon) |
