CMM-3312AT-44308-TR
CUI DevicesUnited States

CMM-3312AT-44308-TR

ObsoleteMicrophones

MIC MEMS ANALOG OMNI 3.3MM D

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Current - Supply80 µA
Voltage Range1.6 V ~ 3.6 V
Voltage - Rated2 V
AC and DC characteristics
Frequency Range100 Hz ~ 10 kHz
Environment and package
Height (Max)0.051" (1.30mm)
PackageTape & Reel (TR); Cut Tape (CT); Digi-Reel®
Size / Dimension0.130" Dia (3.30mm)
Other
Base Product NumberCMM-3312
DirectionOmnidirectional
MfrCUI Devices
Output TypeAnalog
Port LocationTop
Product StatusObsolete
Ratings-
Sensitivity-44dB ±3dB @ 94dB SPL
SeriesCMM
ShapeCircular
S/N Ratio58dB
TerminationSolder Pads
TypeMEMS (Silicon)

Documents

No documents are linked to this part yet.
