View full reportTechnical parameters
| Power | |
|---|---|
| Power - Max | 30 mW |
| Power - Rated | 20 mW |
| AC and DC characteristics | |
| Frequency Range | 300 Hz ~ 6.5 kHz |
| Frequency - Self Resonant | 300Hz |
| Impedance | 32 Ohms |
| Environment and package | |
| Height - Seated (Max) | 0.089" (2.25mm) |
| Size / Dimension | 0.472" L x 0.236" W (12.00mm x 6.00mm) |
| Other | |
| Efficiency - dBA | 110.00 |
| Efficiency - Testing | 1mW/100mm |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Ingress Protection | - |
| Manufacturer | Same Sky |
| Material - Cone | Polyester, Polyethylene Terephthalate (PET) |
| Material - Magnet | Nd-Fe-B |
| Packaging | Tray |
| Part Status | Obsolete |
| Port Location | Top |
| Ratings | - |
| Series | CMR |
| Shape | Rectangular |
| Technology | Magnetic |
| Termination | Spring Type |
| Type | Receiver |
