View full reportTechnical parameters
| Power | |
|---|---|
| Current - Sensing | 5A |
| Current - Supply (Max) | 25mA |
| Number of Channels | 1 |
| Voltage - Supply | 11.4V ~ 12.6V |
| AC and DC characteristics | |
| Accuracy | ±1.9% |
| Frequency | DC ~ 40kHz |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -10°C ~ 75°C |
| Package / Case | Module |
| Other | |
| Base Product Number | CS0512 |
| For Measuring | AC |
| Linearity | ±0.5% |
| Mfr | Same Sky |
| Output | Ratiometric, Voltage |
| Packaging | Tray |
| Part Status | Active |
| Polarization | Unidirectional |
| Response Time | 3µs |
| Sensitivity | - |
| Sensor Type | Open Loop |
| Series | CSXX12U |
