Central TechnologiesUnited States
DC/DC CONVERTER
All alternatives
View full reportTechnical parameters
Key specs
Input voltage4.5 ~ 5.5 V
Output voltage5 V
Output current200 mAMax
Power1 WMax
IsolationIsolated
| Power | |
|---|---|
| Current - Output (Max) | 200mA |
| Power (Watts) | 1 W |
| Voltage - Input (Max) | 5.5V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Isolation | 1 kV |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~85°C |
| Package | Bulk |
| Package / Case | 6-SIP Module, 4 Leads |
| Size / Dimension | 0.65" L x 0.23" W x 0.30" H (16.5mm x 5.9mm x 7.5mm) |
| Supplier Device Package | - |
| Other | |
| Applications | ITE (Commercial) |
| Approval Agency | - |
| Control Features | - |
| Efficiency | 72% |
| Features | - |
| Mfr | Central Technologies |
| Number of Outputs | 1 |
| Product Status | Active |
| Series | CTDD1605SF-SU1K-1 |
| Standard Number | - |
| Type | Isolated Module |
