View full reportTechnical parameters
| Power | |
|---|---|
| Current - Average Rectified (Io) (per Diode) | 30A |
| Current - Reverse Leakage @ Vr | 100 µA @ 400 V |
| Voltage - DC Reverse (Vr) (Max) | 400 V |
| Voltage - Forward (Vf) (Max) @ If | 1.6 V @ 30 A |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Package / Case | SOT-227-4, miniBLOC |
| Supplier Device Package | SOT-227B |
| Other | |
| Base Product Number | DSEI2X31 |
| Diode Configuration | 2 Independent |
| Manufacturer | IXYS |
| Packaging | Tube |
| Part Status | Active |
| Reverse Recovery Time (trr) | 50 ns |
| Series | - |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Standard |
