Rohm SemiconductorJapan
DTA123YCAHZGT116
Single, Pre-Biased Bipolar TransistorsTRANS PREBIAS PNP 0.1A SST3
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Collector Cutoff (Max) | - |
| Current - Collector (Ic) (Max) | 100 mA |
| Power - Max | 350 mW |
| AC and DC characteristics | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 33 @ 10mA, 5V |
| Frequency - Transition | 250 MHz |
| Environment and package | |
| Grade | Automotive |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Qualification | AEC-Q101 |
| Supplier Device Package | SST3 |
| Other | |
| Base Product Number | DTA123 |
| Manufacturer | Rohm Semiconductor |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Active |
| Resistor - Base (R1) | 2.2 kOhms |
| Resistor - Emitter Base (R2) | 10 kOhms |
| Series | - |
| Transistor Type | PNP - Pre-Biased |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 500µA, 10mA |
