View full reportTechnical parameters
| Power | |
|---|---|
| Current - Receiving | 8mA ~ 10.8mA |
| Current - Transmitting | 8.2mA ~ 126.7mA |
| Power - Output | 20dBm |
| Voltage - Supply | 1.8V ~ 3.8V |
| AC and DC characteristics | |
| Frequency | 169MHz, 315MHz, 433MHz, 490MHz, 868MHz, 915MHz |
| Environment and package | |
| Memory Size | 1024kB Flash, 256kB RAM |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C |
| Package | Tray |
| Package / Case | 48-VFQFN Exposed Pad |
| Supplier Device Package | 48-QFN (7x7) |
| Other | |
| Base Product Number | EFR32FG12P431 |
| Data Rate (Max) | 2Mbps |
| GPIO | 31 |
| Mfr | Silicon Labs |
| Modulation | 2FSK, 4FSK, ASK, BPSK, DBPSK, DSSS, GMSK, MSK, OOK, OQPSK |
| Product Status | Discontinued at Digi-Key |
| Protocol | - |
| RF Family/Standard | - |
| Sensitivity | -102dBm |
| Serial Interfaces | I²C, I²S, SPI, UART |
| Series | Flex Gecko |
| Type | TxRx + MCU |
