Espressif SystemsChina
SMD MODULE, ESP32-PICO-V3-02 WIT
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Receiving | 111mA ~ 117mA |
| Current - Transmitting | 248mA ~ 368mA |
| Power - Output | 19.5dBm |
| Voltage - Supply | 3V ~ 3.6V |
| AC and DC characteristics | |
| Frequency | 2.4GHz |
| Environment and package | |
| Memory Size | 8MB Flash, 2MB PSRAM, 448kB ROM, 536kB SRAM |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C(TA) |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 53-SMD Module |
| Other | |
| Antenna Type | PCB Trace |
| Data Rate | 150Mbps |
| Mfr | Espressif Systems |
| Modulation | 8DPSK, DQPSK |
| Product Status | Active |
| Protocol | 802.11b/g/n, Bluetooth v4.2 +EDR, Class 1, 2 and 3 |
| RF Family/Standard | Bluetooth, WiFi |
| Sensitivity | -97dBm |
| Serial Interfaces | ADC, GPIO, I²C, I²S, SDIO, SPI, PWM, UART |
| Series | ESP32 |
| Utilized IC / Part | ESP32-PICO-V3-02 |
