Industrial Fiber OpticsUnited States
CBL FBR OPTIC 2000UM DUPLX 500M
All alternatives
View full reportTechnical parameters
| Environment and package | |
|---|---|
| Operating Temperature | -55°C ~ 85°C |
| Package | Spool |
| Other | |
| Attenuation - Typ | -0.14dB/m |
| Bend Radius | - |
| Cladding Diameter | 2000µm |
| Cladding Material | Fluorinated Polymer |
| Core Diameter | 980µm |
| Core Material | Polymethyl - Methacrylate Resin |
| Features | Zipcord |
| Jacket Color | Black |
| Jacket (Insulation) Diameter | 0.087" (2.21mm) |
| Jacket (Insulation) Material | Polyethylene (PE) |
| Length | 1640.4' (500.0m) |
| Mfr | Industrial Fiber Optics |
| Numerical Aperture | 0.5 |
| Product Status | Active |
| Ratings | - |
| Refractive Index - Core | 1.492 |
| Series | ESKA™ |
| Style | Standard |
| Tensile Strength | 14kg |
| Type | Multimode, Duplex |
