AC/DC CONVERTER 24V 200W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage100 ~ 240 V
Output voltage24 V
Output current6.3 AMax
Power200 WMax
Outputs1
| Power | |
|---|---|
| Current - Output 1 | 6.3 A |
| Power (Watts) | 200W |
| Voltage - Input | 100 ~ 240 VAC |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | 0°C~70°C(WithDerating) |
| Package | Box |
| Size / Dimension | 5.00" L x 3.00" W x 1.25" H (127.0mm x 76.2mm x 31.8mm) |
| Other | |
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus, TUV |
| Efficiency | 90% |
| Features | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input |
| Mfr | SL Power Electronics Manufacture of Condor/Ault Brands |
| Minimum Load Required | No |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | GNT200 (200W) |
| Type | Open Frame |
