Soberton Inc.United States
BUZZER MAGNETIC 1.5V 12MM TH
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Supply | 35mA |
| Voltage Range | 1 ~ 2V |
| Voltage - Rated | 1.5 V |
| AC and DC characteristics | |
| Frequency | 2.73kHz |
| Environment and package | |
| Height - Seated (Max) | 0.346" (8.80mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -20°C~60°C |
| Package | Bulk |
| Size / Dimension | 0.472" Dia (12.00mm) |
| Other | |
| Approval Agency | - |
| Driver Circuitry | Transducer, Externally Driven |
| Duration | - |
| Input Type | Zero-Peak Signal |
| Mfr | Soberton Inc. |
| Operating Mode | Single Tone |
| Port Location | Top |
| Product Status | Active |
| Ratings | - |
| Series | GT |
| Sound Pressure Level (SPL) | 87dB @ 1.5V, 10cm |
| Technology | Magnetic |
| Termination | PC Pins |
