SurgeUnited States
CAP ALUM POLY HYB 100UF 25V SMD
All alternatives
View full reportTechnical parameters
Key specs
Capacitance100 µF
Rated voltage25 V
Tolerance20 %
ESR30 mΩMax
Lifetime4 kh125°C
| Power | |
|---|---|
| Voltage - Rated | 25 V |
| AC and DC characteristics | |
| Ripple Current @ High Frequency | 1.4 A @ 100 kHz |
| Ripple Current @ Low Frequency | 140 mA @ 120 Hz |
| Environment and package | |
| Height - Seated (Max) | 0.315" (8.00mm) |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~125°C |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Surface Mount Land Size | 0.260" L x 0.260" W (6.60mm x 6.60mm) |
| Other | |
| Applications | General Purpose |
| Capacitance | 100 µF |
| ESR (Equivalent Series Resistance) | 30mOhm |
| Lead Spacing | - |
| Mfr | SURGE |
| Product Status | Active |
| Ratings | - |
| Series | HBW |
| Tolerance | ±20% |
| Type | Hybrid |
