HEF4013BTT-Q100
Nexperia USA Inc.Netherlands

HEF4013BTT-Q100

ActiveGates and Inverters

Dual D-type flip-flop

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Power
Power dissipation considerationslow
Environment and package
Automotive qualifiedYes
Halogen freeYes
Package nameTSSOP14
RoHSCompliant
Other
fmax40
Logic switching levelsCMOS
Output drive capability± 2.4
Rth(j-a)139
Rth(j-c)65
Tamb-40~125
tpd30
VCC3.0 - 15
Ψth(j-top)7.1

Documents

DatasheetDatasheet · 245.5 KB · 2026-09-23MarketingMarketing · 6.0 MB · 2026-09-23Package DrawingPackage Drawing · 203.1 KB · 2026-09-23Package DrawingPackage Drawing · 183.5 KB · 2026-09-23Quality & ReliabilityQuality & Reliability · 172.4 KB · 2026-09-23Application NoteApplication Note · 134.5 KB · 2026-09-23Application NoteApplication Note · 95.7 KB · 2026-09-23Application NoteApplication Note · 87.4 KB · 2026-09-23
Open document center
