IC REG CHARGE PUMP INV 8SOIC
All alternatives
View full reportTechnical parameters
Key specs
Input voltage3.5 ~ 7 V
Output voltage2.5 ~ 14 V
Output current120 mAMax
Switching frequency25 kHz
| Power | |
|---|---|
| Current - Output | 120mA |
| Voltage - Input (Max) | 7V |
| Voltage - Input (Min) | 3.5V |
| Voltage - Output (Max) | 14V |
| Voltage - Output (Min/Fixed) | 2.5V (-Vin, 2Vin) |
| AC and DC characteristics | |
| Frequency - Switching | 25kHz |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C~100°C(TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SO |
| Other | |
| Base Product Number | LT1054 |
| Function | Ratiometric, Step-Up |
| Mfr | Analog Devices Inc. |
| Number of Outputs | 1 |
| Output Configuration | Positive or Negative |
| Output Type | Adjustable (Fixed) |
| Product Status | Active |
| Series | - |
| Synchronous Rectifier | No |
| Topology | Charge Pump |
