Microchip TechnologyUnited States
IC OPAMP ZERO-DRIFT 1CIRC SC70-5
All alternatives
View full reportTechnical parameters
Key specs
Supply voltage2.4 ~ 5.5 V
Gain bandwidth product10 MHzTyp
Input offset voltage9 µVTyp
Quiescent current1.1 mATyp
Channels1
| Power | |
|---|---|
| Current - Input Bias | 2 pA |
| Current - Output / Channel | 40 mA |
| Current - Supply | 1.1mA |
| Voltage - Supply Span (Max) | 5.5 V |
| Voltage - Supply Span (Min) | 2.4 V |
| AC and DC characteristics | |
| Gain Bandwidth Product | 10 MHz |
| Slew Rate | 9.5V/µs |
| Voltage - Input Offset | 9 µV |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~125°C |
| Package | Tape & Reel (TR) |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Supplier Device Package | SC-70-5 |
| Other | |
| Amplifier Type | Zero-Drift |
| Base Product Number | MCP6V91 |
| Mfr | Microchip Technology |
| Number of Circuits | 1 |
| Output Type | Rail-to-Rail |
| Product Status | Active |
| Series | - |
