View full reportTechnical parameters
| Power | |
|---|---|
| Current - DC Forward (If) (Max) | 60 mA |
| Current - Hold (Ih) | 280µA (Typ) |
| Current - LED Trigger (Ift) (Max) | 15mA |
| Number of Channels | 1 |
| Voltage - Forward (Vf) (Typ) | 1.15V |
| Voltage - Isolation | 7500Vpk |
| Voltage - Off State | 600 V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Other | |
| Approval Agency | UR |
| Base Product Number | MOC305 |
| Manufacturer | onsemi |
| Output Type | Triac |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Series | - |
| Static dV/dt (Min) | 1kV/µs |
| Turn On Time | - |
| Zero Crossing Circuit | No |
